Paper lid making machine 200

Paper lid making machine 200, speed 40~60 pcs/min, making customize super paper lid cover for bowl bucket container, Otomatis penuh, best quality, low price cost.

Paper lid making machine PL200 info

Firstly, it is designed against the market requirement, makes one piece paper lid cover for cup bowl container, food package.

It is fully automatic machine with the functions:
Automatic roll paper feed, creasing (make the forming guide line),
emboss (can make emboss, logo), hole punch(make hole for straw),
punching (punch the roll paper to lid open disc),
auto feed disc to mold, pemanas, folding, Knurling, and discharge,
with convey and counter for collection,
connect to packing machine, Otomatis penuh.

Aplikasi: Tutup penutup tutup karton kertas untuk wadah mangkuk cangkir, keripik, paket tabung, Paket makanan ringan, Penutup es krim, penutup keju, banyak industri paket.

Specification of Paper lid making machine PL200

Model	PL-100 Roll Feed	PL-140 Roll Feed	PL-Sheet Feed Menyesuaikan	PL-200 Customize model	PL-100D Dome Lid
Kecepatan :	90~100 pcs/minute	60~80 pcs/mnt	50~80 pcs/mnt	40~60 pcs/minute	60~80 pcs/min
Lid Diameter:	50~100 mm	55~140 mm	55~140 mm	100~200mm	55~100mm
Lid Height:	8-15mm (Recommend 10~12mm), Stack lid 11.5mm			10~17 mm	Max 22mm
Bahan:	One & Two side PE/PLA/PBS coated paper, water based barrier paper (KOTKA non-plastic paper). Recommend: PE film coating over 18gsm, Paper best over 0.42~0.44mm 300~320gsm.
Berat kertas	40~ 55 satu (0.40~ 0,55mm, 280~400 gsm), best 300~320gsm			320~350 gsm	Same as PL-100 Model, some parts & molds change.
Total Power :	15 KW;	15 KW;		18 KW
Power Source :	380V 3-fase 50/60 Hz
Total Weight :	2100Kg	2400 Kg	2100 Kg	3000Kg
Machine Size(LWH)	2600 X 1500 X 1800			customize
Sumber Udara :	Tekanan udara: 0.4MPa, Output udara: 100~ 300L/menit;
Kami berhak untuk mengubah spesifikasi tanpa pemberitahuan sebelumnya.

Paper lid making machine Advantage

PLC+HMI+Servo, high speed, intelligent,
one piece/layer paper lid, cost cheaper,
kertas gulungan pakan, Otomatis penuh, less labor,
auto creasing, emboss, make the guide line,
logo engraved, replace print, save cost,
center straw hole cut,
side drink hole punch, coffee, cola, juice,
auto heating, Knurling, make lid,
10 divide tube barrel cam,
10 pcs main mold/tools,
2pcs hot air heating,
Hitungan Otomatis, mengangkut,
connect lid packing machine, Otomatis penuh,

Keuntungan dari tutup penutup tutup kertas

Tutup kertas satu bagian, Biaya murah,
kertas gulungan pakan, Otomatis penuh, Operasi yang mudah,
Nozzle Minuman Mudah/Potong Lubang, Pilih lubang tengah x/o potong atau tidak, Buat tutupnya dingin & minuman normal,
Punch lubang minuman samping sederhana, untuk teh kopi,
Kunci knurling emboss di dalam, dengan desain kunci kertas, mencegah air tersebar,
Ramah lingkungan, Gunakan bahan kertas, semua kontrol plastik dunia atau dilarang, akan menjadi pasar yang bagus,
It is easy to print excellent artwork on paper lid,
Cetak Logo Kustomisasi Luar Biasa, Kustomisasi cetak tutup, dan cocok dengan cangkir kustomisasi,

Shortage of paper lid cover cap

Paper lid can not lock as tightly as plastic lid,
Carton paper lid cover can not make emboss drink nozzle like plastic lid,
Paper cover cap lid can not be re-used as plastic lid, one time use only,
The paper lid will be slowly unfolded/open while water into the lid knurling part (some kind of paper),
Recommend use 2PE paper for paper lid, because 1PE Paper lid will slowly unfold by hot steam ( steam out hole cut),
Quality PE/PLA/PBS film coated paper make quality bio paper lid/cover, Recommend use 2PE paper to make paper lid
