Rippel Duplex Wall Paper Cup manicatam CALLEUS Machina 600h

Ripple double wall paper cup sleeve embossing machine has two station, speed 60~120 pcs/min, feed sheet blank, making embossed ripple double wall cup sleeve, simplex operate, firmum et reliable.

Ripple double wall paper cup sleeve embossing machine info

Uno modo est plene automatic paperboard press apparatus, Pasce laminam blank sheet, Auto formatam figura per fingunt cum calefacientis.

Adopt qualitas hydrau cylindrici formans laminam catino figura, quae providere princeps pressura, magis stabilis et longa vita tempore, humilis sumptus.
Non sicut vetus caeli cylindrici, quae requirere magna potentia compressor, cost altiorem.

Applicatio: emboss ripple double wall cup fan blank, et sic in.

specification of Ripple double wall paper cup sleeve embossing machine

Exemplar: 600H,
Celeritate: 60~120 pcs/minute;
Plate size: 4~13 inch,
Round paper paper max 340mm,
rectangle paper max 320x320mm,
Materia: 100~800 gsm paper/board,
Opus: 8 KW,
Potentia: 380V III-phase 50/60 HZ,
Pondus: 1550/1400Kg,
Magnitudo: 3500x1300x1900mm,
Air Source : Aeris pressura: 0.4MPA, Aeris output: 300L / minute;
Applicatio: emboss sleeve for ripple double wall cup,

Commodum

Two station machine, each station separately operate,
Two station get double speed, save air and power,
Hydraulic coegi pro pneumatic, stabilis pressura,
Plc + HMI cum progressio imperium, intelligens,
Qualis linearibus dux, stabilis et realis,
Hydraulicarius oleum redivivus, redigendum egreditur pollutio, strepitus,
Making embossing ripple double wall cup sleeve,

Adnotatio

Price terminus: FOB Ningbo Portus, SINARUM. (Insurance de Sinis operuit emptori)
Terminus: T / T solucionis (30% depositum, 70% ante partum). ** Emptor est excepit temptare apparatus ante partum.
Delivery Tempus: 30~ L working days ad visus depositum. (re partum tempus dum ordine confirmare)
Sarcina: Latin Export Package. (opus specialis sarcina, Placere info nobis pre).
Praestitus: Anno ex apparatu adventu.
Power Source: Quod potentia fons: 380V III-phase, 50/60HZ (R, S, T, Nympha, Quaeso confirmare potestas fons prius incipit ordinem).

Rippel Duplex Wall Paper Cup manicatam CALLEUS Machina 600h
