India 8sets Paper Cup Machine ZBJ-X12 Ultrasonic

  • ZBJ-X12 Paper Cup Mmachine,
  • Speed: 60~75 cups/minute, 3600~4500 cups/hour,
  • Cup Size: 40ml~12 oz paper cups,
  • Material: One side PE coated paper,
  • Application: Hot drink paper cups, Cold drink paper cups.
  • Machine price $15000/set,
  • Option: cup collector $1000/set,
  • Option: Safety Fence $750/set
BASIC INFO

ZBJ-X12 India Paper Cup Machine Video

ZBJ-X12 Paper cup making machine Advanced :

  • 1, Gears & Axis control movement, two index gear box, more efficient & accurate.
  • 2, HMI & PLC Program computer control, easy operate, fault auto-stop and easy solution.
  • 3, All procedure sensor detect (11-sensor control all step), Less wastage & fault, Reliable.
  • 4, Self lubrication (Automatic Oil Lubrication for machine moving part), long life time.
  • 5, Import electric Elements, Superior Bearing & Quality material, more durable and reliable.
  • 6, Working power only 3.5KW, save electric power cost.
  • 7, One worker can run 2sets machine (machine assemble cup stock), save labor cost.

ZBJ-X12 India Paper Cup Machine description:

Paper Cup Forming Machine is an automatic machine with multi-working station, which has the function of photocell detection, failure alarm, counter and the advantages of humanism design, safer operation and easier maintenance.

It makes both one-side and two-side PE-film-coated paper cups after running a whole procedure of automatic Multi-step pre-printed-cup-fan-paper Feeding (Multi-step paper-feed and Anti-back device to keep the accurate position), cup-wall-side welding(ultrasonic wave), robot transfer cup body, silicone-oil lubricating(for top curling, Dimethyl silicone oil 201,Food Grade), bottom-disk punching, bottom pre-heating and pre-folding, main heating, bottom knurling(cool device for 2PE), top curling, cup discharging, collecting, blowing, pipe transfer to count and pack desk.

It is an ideal equipment of making 3~16oz paper cups(hot drink paper cup, cold drink paper cup, coffee paper cup, tea paper cup, ice cream paper cup, juice paper cup, milk paper cup, etc).



ZBJ-X12 India Paper Cup Machine specification:

Model ZBJ-X12 ZBJ-X16
Rated Speed: Actual 65~75cups/m (4~12oz)
60~75 cups/minute
55~70 cups/minute
Paper Cup Size: 3 ~ 16 oz 8~22 oz
Raw Material: One-side or two side PE(polyethylene)film coated/laminated paper;
Suitable paper weight: 180~350gsm
Power Source: 50Hz, (220V single phase, 380V 3-phase, 50Hz),
(Better use 380V 3-phase)
* if User power different? Please INFO US IN ADVANCE.
Total Power: 6KW 6KW
Working Power: 3.5 KW 3.5 KW
Total Weight: GW/NW: 2750KG/2600KG GW/NW: 2950KG/2800KG
Pack Size (L*W*H) 2750 x 1240 x 1800 mm 2800x1300x1900
Working Air Source: Air pressure:0.4Mpa;  Air Out-put:0.6m³/minute
User should BUY Air Compressor
Cup Side Welding: Ultrasonic
Cup Bottom Heating: Hot Air  (Air compressor supply air)
Cup Bottom Knurling: Heater Knurling (if use single PE coated paper)
Cool Device (circle water) knurling, for double PE coated paper
Available to make special machine & molds on user order.
