ZBJ-H12 Ultrasonic Paper Cup Machine 45~55 pcs/m

  • Speed: 45~55 cups/minute,
  • Cup size: 3~12oz (mold exchangeable ),
  • Material: Single & Double side PE coated paper cups ( 1PE paper ),
  • Paper thickness: 150~350gsm (cup wall seal by ultrasonic),
  • Machine Price: $1000/set,
  • Option: cup collector $1000/set,
  • Option: Safety Fence (Plastic-glass) $750/set,
BASIC INFO Payment & Delivery Service Contact

ZBJ-H12 Ultrasonic Paper Cup Forming Machine Video

ZBJ-H12 Ultrasonic Paper cup forming machine Specification:

Model ZBJ-H12
Rated Speed: 45~60pcs/minute 40~45pcs/m 35~45pcs/m 30~40pcs/n
Cup Size Range: Mold Exchangeable
3~12oz 8~16oz 12~22oz 16~32oz
Top Diameter : 45~110 mm 60~120 60~120 60~120
Bottom Diameter : 30 ~ 80 mm 50~90 50~100 50~100
Cup Height : 40~115 mm 45~145 80~180 100~220
Suitable PE Paper One PE Paper Both ONE or TWO Side PE Coated Paper
Suitable paper weight: 140~250gsm 140~350gsm  (Max 450gsm)
Cup Wall Welding: Heater Sealing Ultrasonic Sealing
Cup Bottom Heating: Heater Hot Air  (Need Air compressor to provide the air)
Cup Bottom Knurling: Heater Knurling Heater Knurling ( One side PE paper)
Cool Device (circle water) Knurling  (For Two Side PE Paper)
Working Power: 3.3KW 3.3~3.5KW
Total Power: 4.8KW 6KW
Working Air Source: NO need Air pressure:0.2~0.4Mpa;  Air Out-put:0.6m³/minute
User should BUY Air-compressor .
Power Source: 50/60Hz, 380V/220V (better use 380V, 3-phase).
(Your Power different?  Tell us in Advance to avoid mistake)
Total Weight: (GW/NW) 1500KG/1350KG 1800KG/1650 2200KG/2000 2500KG/2300
Pack Size (L*W*H) m 2.75×1.24×1.7 m 2.75×1.3×1.7 3×1.3×1.9 3.2×1.4×2.1 3.5×1.5×2.2

ZBJ-H12 Ultrasonic Paper cup forming machine description:

ZBJ-H12 Ultrasonic Paper Cup Forming Machine is an automatic machine with multi-working station, which has the function of photocell detection, failure alarm, counter and the advantages of humanism design, safer operation and easier maintenance.

It makes both double and single PE-film-coated paper cups after running a whole procedure of automati pre-printed-cup-fan-paper Feeding (Two-step paper-feed and Anti-back device to keep the accurate position), Cup-wall-side welding(ultrasonic wave), robot transfer cup body, silicone-oil lubricating (for top curling, Dimethyl silicone oil 201,Food Grade), bottom-disk punching, bottom pre-heating and pre-folding, main heating, bottom knurling(cool device for 2PE), top curling, cup discharging, collecting.

It is an ideal equipment of making 3~12oz hot drink paper cups(coffee paper cups, tea paper cup, etc), cold drinks paper cups ( cola paper cups, juice paper cups, pepsi paper cups, ice cream paper cups, etc).


  • Price Given on T/T Payment, (Extra US$1000/Shipment For L/C Payment.)
  • Price Term: FOB Ningbo port, China.
  • Payment: T/T( 30% deposit, 70% before delivery) or L/C.
  • Lead Time: 30~45 working days at sight the deposit.
  • Packaging: Seaworthy Wooden Packing.
  • 1 year guarantee, Spare parts guarantee for one year. All life time support.
  • English manual, Video. Questions response within 48 hours.
  • Send technician for installation & training, the cost cover by buyer ( round tickets,accommodation, an allowance of USD80 a day).
