Aluminium foil take away food box machine 1600S double line

Aluminium foil take away food box machine 1600S double line, full servo, double speed, two working station, each station separately working.

It is almost two pcs 800s cartong erecting machine combine together.

800S carton erecting machine, high quality full servo motors driven, speed 50~200pcs/min, make carton paper box container tray, easy operate, change mold to make different shape size.

Aluminium foil take away food box machine 1600S double line

Features: Adopt servo motor to control the machine, especially the full servo motor drive model, Main servo, feed servo, forming servo, drive servo,easy operate, easy change mold, easy set.

• Compact structure, Strong frame, keep the machine reliable and durable with low noise.
• Hard Plastic-glass cover, Safe and visible for user.
• Easy exchange molds to make different products, charging and adjusting time is very short.
• PLC program control the whole line, available to make complicated boxes.
• Automatic collection, stock, and count.
• Human being designed control button and panel, more easy and safe runs by user.

Application: hamburger box, chips tray box, doner box, take away box, hot dog box, kraft food boat tray, and so on.

Specification of Carton erecting machine 800s

• Model: 800 4S,
• Speed: 50~200 pcs/minute, one line,
• Paper size: 100×100 ~ 450x600mm,
• Welding method: Water-glue adhesive,
• Material: 200~600gsm carton cardboard paper,
• Material thickness: Max. 1.5mm,
• Total power: 5KW,
• Electric power : 380V 3-Phase 50/60 Hz,
• Size: 3600 x 1500 x 1700 mm,
• Weight: 2000KG,
• Need Air (pressure:0.6Mpa, Output:300~500 L/m),
• Available to make machines and molds on user order,
• Application: burger box, boat tray, take away box, friex box,

specification of Aluminium foil take away food box machine 1600S double line

• Model: 1600 8S , 8pc servo,
• Speed: 40~180 pcs/minute (one station), double line,
• Paper size: Max. 450x400mm,
• Weight: 2700KG,
• Size: 3600 x 2050 x 1700 mm,

Advantage

• four servo drive, simple operate, less maintenance,
• Double line 1600, double speed, two box ,
• Servo feed paper, easy change mold, smoothly,
• PLC+HMI with program control, intelligent,
• Servo convey, stable and reliable,
• Quality servo drive forming, directly, easy handle,
• Making carton tray box container,

Box tray shape

• One block paper box, 4-corner box without cover, Max. 200pcs/min,
• Fries chips box tray: Max. 150pcs/min,
• Burger box,hot-dog box : Max. 150pcs/min,
• Food pail, DEEP take away to go box: Max. 100pcs/min,

Aluminium foil take away food box machine 1600S double line

Aluminium foil take away food box machine 1600S double line

Carton erecting machine – paper food burger fries box making
