Servo paper cup machine
Vietnam paper cup machine 22oz ripple double wall new, production speed is up to 150 pcs/min, make and wrap a 2nd layer jacket sleeve around inner single wall paper cups.
Produce two layer paper cups, anti scalding coffee cup, hot insulation paper cups.
Entirely servo drive, Best price cost, Quality Stable Tntelligent Fully automatic.
Vietnam paper cup machine ripple double wall:
Vietnam ripple double wall paper cup sleeve machine, produce ripple wall paper cup, double wall paper cups against customer size. Double wall style: hollow paper cups, ripple/corrugated paper cups, embossed paper cups. The double wall paper cup production process list below:
- Feed double wall sleeve on the fan seender and entry,
- Auto suck the sleeve fan, feed to machine,
- Auto seal the sleeve wall side, Ultrasonic sealing (copper option ), (add Hot melt glue spray, option),
- Lift sleeve wall to main mold, bottom fold, knurling (hollow double wall cup sleeve),
- Drop and transfer sleeve wall to stick-plate,
- Spray a circle water glue (servo motor control, rotate a circle) inside the sleeve wall,
- Servo feed single wall cup into sleeve wall,
- Push the sleeve into single wall cup rim space,
- Discharge, count and collect.
Specification of Vietnam paper cup machine ripple double wall
- Model: 150S DW16,
- Speed: up to 150 pcs/minute,
- Cup size: 4~16oz,
- Top: 45~100 mm,
- Bottom: 30~72 mm,
- Height: 30~135 mm,
- Material: 150~320gsm film coated paper, paper with glossy/varnish print,
- Water glue stick the double wall sleeve and inner cup.
- Water Glue: (polyvinyl acetate emulsion),
- Option: Hot melt glue for side wall sealing, and so on.
- Weight: 3000KG,
- Machine:3200x1650x2100mm,
- Collector: 900 x 700 x 2100mm (against cup size )
- Total power: 30KW (working power 8KW),
- Power: 380V 3-Phase 50/60 Hz,
- Need Air (pressure:0.3~0.5Mpa, Output:300~500 L/m),
- Application: ripple double wall paper cups bowl container,
How to make ripple double wall paper cups?
To produce ripple double wall paper cups, require two machines working together,
- 1st, 150S servo paper cup machine, produce single wall paper cups, all servo driven, 150 pcs/minute.
- Add a mid-transfer system, collect and transfer single wall paper cups to double wall sleeve machine,
- 2nd, ripple double wall paper cup machine , seal the 2nd layer sleeve, and wrap the sleeve/jacket around single wall cups, all servo driven, 150 pcs/minute.
- 3rd, paper cup packing machine, produce 3-side bag, packaging paper cups into plastic / paper bags.
- Whole line, fully automatic, high speed, stable, intelligent.
Picture:
Vietnam paper cup machine 22oz ripple double wall new
